Our RF/Radio Testing Laboratory has a complete and powerful radio equipment RF testing laboratory with years of experience in radio equipment management and testing. The testing capability covers RF testing of almost all radio communication and non-communication equipment. Customers provide professional RF testing services.
Our's Services:
RF/radio single test site rental;
Product certification services, obtained certification from national certification bodies;
National regulations for wireless transceivers test / report issuance and application
Domestic low-power RF motor control test / countermeasure service / report issuance and application
Communication product testing / report issuance and application services
National regulations and wireless / mobile / communication technology information consulting / counseling and training
Domestic and international wireless RF testing / countermeasure services / report issuance / application
Mobile EMC Test / WiMAX EMC Test / CTIA TRP / TIS Test
MIMO test / DFS Master / Slave test
| Product Category | Product service range |
|---|---|
| Wireless products | Wearable device, security device, walkie-talkie, wireless microphone, remote control, wireless network device (WiFi 802.11 a/b/g/n/ac), wireless image transmission system, Bluetooth (BT 2.1 EDR/ BT3.0 HS / BT4 .1 LE), Zigbee products, 802.11ad/Wigig/WiHD, SRD/NFC/RFID/Z-Wave/cc1110, product wireless keyboard/mouse/USB Dongle and other low-power wireless transceivers. |
| Wireless communication products | 2G(GSM/DCS/PCS)、3G(WCDMA / HSPA /HSPA+/ CDMA2000/CDMA EVDO)、4G(LTE)、DECT、Mobile phones and other mobile device products. |
| Communication products | Telephones, wired telephones, wireless main and auxiliary machines, fax machines, telephone recorders, modems, data adapter cards and other communication products. |
Wireless product testing standard:
EN 301406 (DECT Phone)
EN 300086 EN300 296 EN 300 113 EN 301 166 (Land mobile radio)
EN300 220-1/2, EN300 330-1/2,EN300 440-1/2,EN 302 291(SRD product)
EN300 328,EN 301 893,EN 302 502(2.4GHz,5GHz,Bluetooth,WiFi)
EN300 422-1/2,EN301 357-1/2(Audio product)
EN301 489-1/-3/-7/-9/-17(EMC standard)
FCC Part 15B/C/E/Part 22H/Part 24E /FCC Part 27/FCC Part 74/Part 90/Part 95
RSS 210,RSS 310,RSS 247
AS NZS 4268 (Autralian)
ARIB STD-T33,ARIB STD-T66,ARIB STD-T67 ,ARIB STD-T71
ARIB STD-T91(Janpan)
DFS Master & Slave test:
EN 301 893 (802.11a/n/ac)
EN 302 502
FCC Part 15.407
Japan DFS test
Wireless communication (2G/3G/4G) product testing:
EN 301 489-7 (GSM / GPRS / EDGE)
EN 301 489-24 (LTE / WCDMA / HSDPA / HSUPA )
EN 301 489-25 (CDMA2000 / EVDO Rev A / EVDO Rev B)
EN 301 511
EN 301 908-1&2 (WCDMA / HSDPA / HSUPA)
EN 301 908-1&13 (LTE)
EN 301 908-1&4 (CDMA 2000 / EVDO Rev A / EVDO Rev B)
FCC Part 15B
FCC Part 22H
FCC Part 24E
FCC Part 27
GCF CC
PLMN01
PLMN08, PLMN09 RTTE01 / LP0002
RSS 132 & 133 & 139
Common test items
| Frequency error | Duty cycle | Blocking |
| Radiated carrier power | Phase error | Intermodulation attenuation |
| Conducted carrier power | Transient power | Frequency response |
| Radiation spurious(<26.5GHz) | Adjacent frequency power | Adjacent channel signal selectivity |
| Conducted spur | Modulation bandwidth | Scatter signal suppression |
| Power spectral density | Power flatness | Intermodulation immunity |
